Shenzhen Baige Medical Technology Co,. ltd.
We are professional supplier of Anesthesia ventilator,Patient monitor,Injection bump,Vaporizer,AGSS.
Business Type:Manufacturer
Country/Region:China
Ddu Verified
HOT Rank
| DIMENSIONS(W*H*D) | 78.2*142.5*71.9CM | |
| POWER AND BATTERY BACKUP | ||
| Power Input | 100-240V, 50/60 Hz | |
| Operation time with fully charged batteries | 60 minutes minimum (up to 90 minutes) | |
| GAS SUPPLY MODULE | ||
| Gas input | O2, N2O, AIR; 280kPa - 600kPa | |
| O2 flush | 25L/Min-75L/Min | |
| O2-N2O link system | O2 concentration not lower than 25% O2 concentration:21-100% | |
| VENTILATOR SPECIFICATIONS | ||
| Control Screen | 10.4 inch, color touch screen | |
| Ventilator | Electronically controlled, pneumatically driven | |
| Ventilation modes | Manual, VCV, PCV, options: SMIV-VC/PC, PSV | |
| Vt | 20-1500 ML | |
| PEEP | OFF, 4-30cmH2O | |
| Insiration pause (Tip:Ti) | OFF, 5%-60% | |
| Slope | 0-2s | |
| Compensation | Compliance compensation, fresh gas compensation | |
| Monitoring Parameters | Ppeak, Pplat, PEEP, Pmean, FiO2, R, C, Vt, MV, Rate, I:E, ETCO2, FiN2O, Waveforms(F-T, P-T, V-T, ETCO2-T), Loops(F-V, P-V, P-F), AG, MAC | |
| Alarms | Tidal volume, Rate, MV, Apnea Alarm, Airway pressure; Low Driven Gas Pressure, Low Battery, Status of Breathing system | |
| VAPORIZER | ||
| Type | Enflurane, Isoflurane, Sevoflurane | |
| Mounting Mode | Selectatec type wtith interlock | |
| Filling type | Pour-fill | |
| INTEGRATED BREATHING SYSTEM | Built-in heated, Autoclavable, Bypass function Volume of CO2 absorber canister:1600ml | |
| CERTIFICATES | ||
| CE Mark | Anesthesia machine, vaporizer | |
| ISO 13485 | Yes | |
